Reference system to be used for simpliflying the definition of point positions. More...
#include <SisRef.h>
Public Member Functions | |
| SisRef (Preprocessor *m) | |
| Constructor. | |
| SisRef (const std::string &nombre="", Preprocessor *m=nullptr) | |
| virtual Vector3d | GetVDirEje (const size_t &, const Pos3d &) const =0 |
| Returns the i-th axis unit vector for the position being passed as parameter. | |
| Vector3d | GetI (const Pos3d &) const |
| Return the ${i}$ unit vector expressed in the global coordinate system for the position passed as parameter. | |
| Vector3d | GetJ (const Pos3d &) const |
| Return the ${j}$ unit vector expressed in the global coordinate system for the position being passed as parameter. | |
| Vector3d | GetK (const Pos3d &) const |
| Return the ${k}$ unit vector expressed in the global coordinate system for the position being passed as parameter. | |
| virtual Pos3d | GetPosGlobal (const Pos3d &p) const =0 |
| Return the global coordinates of point p. | |
| virtual Vector3d | GetCooGlobales (const Vector3d &v) const =0 |
| Return the global coordinates of vector v. | |
| virtual Pos3d | GetPosLocal (const Pos3d &p) const =0 |
| Return the local coordinates of point p. expresada en coordenadas locales. | |
| virtual Vector3d | GetCooLocales (const Vector3d &v) const =0 |
| Return the local coordinates of vector v. | |
 Public Member Functions inherited from XC::EntMdlrBase | |
| EntMdlrBase (const std::string &nmb="", Preprocessor *preprocessor=nullptr) | |
| Constructor. | |
| EntMdlrBase (const EntMdlrBase &otro) | |
| Copy constructor. | |
| EntMdlrBase & | operator= (const EntMdlrBase &otro) |
| Assignment operator. | |
| const Preprocessor * | GetPreprocessor (void) const |
| Preprocessor * | GetPreprocessor (void) |
| size_t | GetTag (void) const |
| Return the object identifier in the model (tag). | |
| Pnt * | BuscaPnt (const size_t &) |
| Return a pointer to the point identified by the tag being passed as parameter. | |
| const Pnt * | BuscaPnt (const size_t &) const |
| Return a const pointer to the point identified by the tag being passed as parameter. | |
| Edge * | BuscaEdge (const size_t &) |
| Return a pointer to the edge identified by the tag being passed as parameter. | |
| const Edge * | BuscaEdge (const size_t &) const |
| Return a pointer to the edge identified by the tag being passed as parameter. | |
| Face * | BuscaFace (const size_t &) |
| Return a pointer to the face identified by the tag being passed as parameter. | |
| const Face * | BuscaFace (const size_t &) const |
| Returns a pointer to the face identified by the tag being passed as parameter. | |
| virtual int | sendSelf (CommParameters &) |
| Send objects through the channel being passed as parameter. | |
| virtual int | recvSelf (const CommParameters &) |
| Receive objects through the channel being passed as parameter. | |
| Public Member Functions inherited from XC::MovableObject | |
| MovableObject (int classTag, int dbTag) | |
| Constructor. | |
| MovableObject (int classTag) | |
| Constructor. | |
| MovableObject (const MovableObject &otro) | |
| Copy constructor. | |
| MovableObject & | operator= (const MovableObject &otro) |
| Operacdor asignación. | |
| int | getClassTag (void) const |
| Returns the tag de la clase. | |
| int | getDbTag (void) const |
| Returns the tag para la database. | |
| int | getDbTag (CommParameters &) |
| Returns the tag para la database. | |
| void | setDbTag (int dbTag) |
| Asigna el tag para la database. | |
| void | setDbTag (CommParameters &) |
| Asigna, sólo si es preciso, el tag para la database. | |
| virtual int | setParameter (const std::vector< std::string > &argv, Parameter ¶m) |
| virtual int | updateParameter (int parameterID, Information &info) |
| virtual int | activateParameter (int parameterID) |
| virtual int | setVariable (const std::string &variable, Information &) |
| Returns the identificador de la variable cuyo nombre being passed as parameter. | |
| virtual int | getVariable (const std::string &variable, Information &) |
| Public Member Functions inherited from XC::DistributedBase | |
| DistributedBase (void) | |
| Constructor. | |
| virtual DbTagData & | getDbTagData (void) const |
| Returns a vector to store class dbTags. | |
| const int & | getDbTagDataPos (const int &i) const |
| Returns the data at the i-th position. | |
| void | setDbTagDataPos (const int &i, const int &v) |
| Sets the data at the i-th position. | |
| void | inicComm (const int &dataSize) const |
| Initializes communication. | |
Additional Inherited Members | |
| Protected Member Functions inherited from XC::EntMdlrBase | |
| const Preprocessor * | get_preprocessor (void) const |
| Return a pointer to the preprocessor. | |
| Preprocessor * | get_preprocessor (void) |
| Return a pointer to the preprocessor. | |
| bool | check_preprocessor (void) const |
| Check for preprocessor. | |
| int | sendIdsEtiquetas (const int &, const int &, CommParameters &) |
| Send labels through the channel being passed as parameter. | |
| int | recvIdsEtiquetas (const int &, const int &, const CommParameters &) |
| Receive labels through the channel being passed as parameter. | |
| int | sendData (CommParameters &) |
| Send members through the channel being passed as parameter. | |
| int | recvData (const CommParameters &) |
| Receive members through the channel being passed as parameter. | |
| Protected Attributes inherited from XC::EntMdlrBase | |
| LabelContainer | labels |
| Label container. | |
Reference system to be used for simpliflying the definition of point positions.
